SGM-Lektra 114CH

Specification:

The 114CH conductivity sensor, connected to the MCA800 unit, is used for conductivity measurement in wastewater, industrial water, and recirculation water.
Reliable 4-electrode conductive measurement method using temperature-compensated graphite electrodes.

Max. measurement accuracy ≤4% on the reading point

Four-electrode measuring method with temperature compensation

Measuring range from 1μS/cm to 200mS/cm

Max. operating temperature 100°C

Maximum pressure 5 bar

Transmission of measurements via RS485

MODBUS RTU digital communication

Match with MCA800 control unit
